BLAST PROTECTION

Blast protection products from ASL GRP

We supply rigid and flexible blast suppression products to clients around the world. Our blast protection solutions are designed to keep personnel safe whilst awaiting the arrival of EOD disposal operators.

Blast Container

The Blast Container is a cylindrical assembly consisting of composite woven fibres, designed to withstand blast and fragments from an explosive device containing up to 500g (16 oz.) of PE4 (TNT).

The container enables the user to contain a suspect explosive device while awaiting the arrival of a bomb disposal team. The container has a marked datum point on the outside face, designed to assist the bomb disposal team in scanning and determining the threat and appropriate action required.

The exterior is fitted with two rubber rings to allow the container to be easily manoeuvred into position and each unit is coated in a highly visible day glow orange.

The container consists of the main unit and removable retaining bag with handles.

    Nominal dimensions and specifications:

    • Maximum charge capacity – 500g
    • Height – 900mm
    • Outer diameter – 553mm
    • Inner diameter – 517mm
    • Wall thickness – 18mm
    • Weight – 47kg

    Click here to download product details.

    Blast containment bin ASL GRP

    Blast Suppression Blanket

    Blast suppression blankets are used to suppress the blast fragmentation from an explosion that can cause damage and injuries.

    These blankets are particularly useful for suspected IEDs contained in packages up to briefcase size and pipe bombs.

    The multiple layer ballistic material is enclosed in a heavy-duty nylon, water-resistant cover which is fitted with lifting straps and clearly marked DANGER.

    Both blanket and circle fold into a compact, easily carried holdall bag. This soft armour can also be used where there may be weight limitations i.e. vehicle protection – floor and bulkhead protection.

    Available at 400m/s or 500m/s protection levels. Click here for futher details and a demonstration of how the Blast Suppression Blanket is deployed.

    Click here to download product details.



    Blast suppression blanket

    Folding Blast Container

    The ASL GRP folding blast container is a a light-weight, easy to assemble, and store, containment vessel.

    The folding blast container will contain a suspect explosive device while awaiting the arrival of a bomb disposal team.

    Designed to withstand blast and fragments from an explosive device containing up to 200g of PE4.

    When folded into its storage position, the container will fit in the spare tyre compartment of a vehicle, ideal for Police, fire or security fleets.

    Fold points are stitched in red. Quick pressure should be applied to the centre ring diagonals, which naturally makes the container twist.

    Repeat the process until all three ring sections have collapsed. Apply pressure to the top of the folded container to compress further.

    Click here to download product details.





    Folding blast container

    Below is our blast data table relating to the materials we use for our various armour options.
